King Mine-Air Mining Air Hoist
MINE-AIR KAH-M SERIES MINING AIR HOIST
Features:
Design, manufactured, certified & tested in compliance with SANS 1638.
Design registered under the Design Act of 1993.
5:1 Factor of Safety at WLL rating.
Designed to perform at WLL in the working air pressure range of 3.5 – 6.3 bar.
Zinc plated, corrosion & abrasion resistant, case-hardened, 12.5mm diameter Grade 80 DAT Load Chain in conformance with SANS 3077, exceeds 6:1 factor of safety.
Pendant Control operation to isolate operator from the suspension zone and load path or optional chain type toggle control.



KAHM-LP LOW AIR PRESSURE MINING HOISTS
Features:
Designed for vertical lifting & horizontal pulling operation for mining applications and conditions.SAFE & FIT FOR PURPOSE.
Bolted hook covers to allow shank wear inspection and lubrication.
Dual brake system – Friction & Cone brake.
Exceeds 5:1 factor of safety at WLL rating.
Designed to perform at WLL in a 3-6 bar working air pressure range.
Heavy duty, retractable, carry handles located on both ends of the hoist.
High starting-torque air motor design.




KAHM-LP LOW AIR PRESSURE MINING HOIST P4 SERIES
Features:
Designed, manufactured & tested in compliance with SANS 1638.
Dual brake system – Friction & Cone brake.
Remote air connection for safety if Air Hose becomes disconnected or damaged.
Lube free, low friction material vanes & internal motor long-life automatic lubrication system.
6:1 Safety factor at maximum WLL rating.
Heavy duty retractable carry handles on either sides of the hoist.
High starting torque Air Motor.
